Description
Charging & Safety:
– Equipped with an emergency stop button and anti-shock grounded socket.
– Fixed 12″ extended entrance for safe and convenient material loading.Pre-Wash Section (12″)
– One spray system with four quick-connect boom systems (32 nozzles total).
– External water supply controlled by a valve and monitored via a water meter.
– Wastewater is discharged directly into the drainage system.Cleaning Section (36″)
– Three 9 kW immersed coil heaters installed in the front cabin for easy maintenance.
– Includes overheat protection and redundant low-water flow protection devices.
– Automatic water addition system with precise volume control.Isolation Flush Section (33″)
– Prevents chemical carry-over from the wash tank to the rinse tank.
– Enhances liquid penetration under parts for thorough cleaning.
– Features one upper and one lower adjustable air knife tube and two quick-connect boom systems (16 nozzles total).
– External water supply monitored and controlled by valve; wastewater drains directly.Unloading
– Emergency stop button and anti-shock grounding for safety.
– Sound- and noise-reduction cover.
– Stainless-steel exit ramp for smooth handling.Conveyor System
– Full 18″ width with guides aligning PCBAs directly with booms and air knives.
– Constructed from 302 stainless steel; standard 0.5 pitch/0.072″ wire belt (optional 0.375 pitch upper strap).
– Sliding-clutch protected drive for reliability.
– Anti-static grounding ensures safe operation.
