Description
Technical Parameters
– The machine has overall dimensions of 3600 mm (length) × 2020 mm (width) × 1750–1800 mm (height) and weighs approximately 1,500 kg.
– It operates on a three-phase 380 VAC electrical supply, with a general power rating of 78 kW and a power consumption range of 20–50 kW.
– The exhaust system includes two 8-inch suction openings with a total airflow capacity of 2,000 CBM/h.
– Water input requirement is 8–20 l/min, varying based on selected options and configurations.
– The conveyor system features a 600 mm wide stainless steel mesh belt with a conveyor height of 940 ± 20 mm.
– Conveyor speed is adjustable from 100 mm to 1000 mm.
– Conveyor clearance is 70 mm, with an optional clearance of 120 mm.
– Conveyor direction is left-in, right-out.
