Description
Technical Parameters:
– The machine dimensions are L2860 mm × W1650 mm × H1650 mm and it operates on a three-phase five-wire 380 V, 50 Hz power supply.
– The rail adjustment range is 100–600 mm, with a transport height of 900 ± 30 mm.
– When using a double tin furnace, the system supports PCB sizes up to L450 mm × W500 mm, with a maximum single-board size of 450 × 240 mm.
– The machine features a lightweight cast aluminum platform with ball screw and Panasonic servo control, achieving movement accuracy of ±0.05 mm.
– The tin furnace system supports single or double cylinders, each with a capacity of 13 kg, and uses a standard mechanical pump with an optional electromagnetic pump.
– Nitrogen consumption is approximately 1.5–2 m³/h per tin cylinder.
– The system supports online and offline programming and is compatible with picture and Gerber file inputs.
