Description
Technical Parameters
– The transport height is 900 ± 30 mm.
– The machine features a lightweight cast aluminum platform with ball screw and Panasonic servo control, achieving a movement accuracy of ±0.05 mm.
– The tin furnace system uses a standard mechanical pump with an optional electromagnetic pump and is configured with a single cylinder.
– Each tin furnace has a capacity of 13 kg, with nitrogen consumption of approximately 1.5–2 m³/h per tin cylinder.
– The system supports both online and offline programming and is compatible with picture and Gerber file inputs.
