Description
Model 2 Key Features
World’s largest off-line cleaning cavity for its class: L690 × W620 × H715 mm; accommodates larger PCBA assemblies or higher batch volumes.
Double-layer basket design (L610 × W560 × H100 mm): Increases throughput while maintaining cleaning uniformity.
360° rotating spray cleaning: Ensures complete flux and residue removal from all sides of PCBAs.
Chemical liquid recovery & filtration (0.45 μm): Removes tiny contaminants like solder paste, rosin, and flux, improving fluid reuse and cleaning consistency.
Precise temperature control: Cavity and drying heaters adjustable from room temperature to 99 °C for sensitive component cleaning.
High-capacity solvent and diluent tanks: 30 L concentrate, 70 L diluent, and 17–23 L sprinkler tank for extended operation without frequent refills.
High-power cleaning and drying systems: 6 kW cavity temperature compensation, 9 kW solvent heater, 6 kW drying heater, and 5.5 kW horizontal spray pump for efficient operation.
Resistivity meter monitoring (0–18 MΩ·cm): Ensures high-quality water and process control during cleaning cycles.
Quick-install interfaces for water intake and drainage (1 inch): Reduces setup time and simplifies maintenance.
Compact yet robust footprint: Physical dimension L1200 × W1100 × H1830 mm, net weight 400 kg; stable operation with manageable floor space.
